    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR
    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR
    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR
    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR
    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR

    Bigger Pilot 7" LCD High Brightness Monitor with 5.8 GHz Receiver and DVR

    Sold Out

    Notify me when this product is available:

    The 7" Ground Station LCD features a bright screen which can be used in direct sunlight and a built in DVR.

    This is our favorite outdoor LCD , plus is has a great and easy to use DVR .

    Features:

    Auto channel searching function.

    On screen voltage indicator.

    On screen operation timer.

    On screen signal strength indicator.

    Auto backlight dimming based on ambient light sensor.

    Specifications:

    Specifications:
    Resolution: 800 x 480
    Backlight: LED
    Backlight Brightness: 700 Lux
    Screen Ratio: 16:9
    Response Time: 10ms
    Formats: PAL/NTSC
    Working Voltage: DC: 2S – 6S Battery
    Working Current: 850mah @ 12V
    Battery input connector: Deans T-Plug
    1.4A @ 7.4V
    Input: Video (PAL/NTSC), Audio
    Output: Video, Audio
    DVR resolution: D1/VGA/QVGA
    Max Support: 32G TF Card
    Antenna Connector: RP-SMA
    5.8G sensitivity: -94dB
    Package Weight: 0.66kg
    Dimension: 250mm x 130mm x 106mm
