Specifications:
KV................................................................................................................330
Configu ration...................................................................................18N24P
Stator Diameter...................................................................................40mm
Stator Length.......................................................................................14mm
Shaft Diameter.......................................................................................4mm
Motor Dimensions(Dia.*Len)...........................................Φ44.8×34.5mm
Weight (g)................................................................................................149g
ldle current(10)@10v(A).........................................................................1.1A
No.of Cells(Lipo)....................................................................................4-8S
Max Continuous current(A)180S...........................................................25A
Max Continuous Power(W)180S.......................................................750W
Max. efficiency current.............................................................(3-10A)>84%
internal resistance...............................................................................85mΩ
